EuroCave Compact Range Small Cellar Model 059
The EuroCave Compact Range Model 059 is a premium small wine cellar designed for collectors who want professional-grade storage in a compact footprint. This single-temperature wine cabinet is ideal for long-term wine storage when set around 12°C, or for serving a single wine style at 7°C (whites) or 17°C (reds).
Originally engineered to fit seamlessly into a standard 60 × 60 cm kitchen space, the Model 059 features front ventilation, allowing it to be installed under-counter without rear clearance. Ventilation occurs through the front grille, producing a low, consistent fan noise. For proper airflow, the front grille must remain unobstructed and cannot be plinth-covered.
Choose between multiple shelving configurations to suit your collection, including the highly popular four sliding shelf layout for effortless access. Door options include a UV-filtered glass door for visibility, a solid black laminate door, or a technical door (3.2 kg) designed to accept a custom cabinetry panel. This model is manufactured exclusively in black laminate for a refined, understated look.
***** Additional Information *****
Design
- Full glass door with black exterior (as shown)
- Solid black door or technical door ready to receive a custom cabinetry panel
Capacity
-
Standard configuration: 38 bottles
(4 sliding shelves holding 8 bottles each + 6 bottles stored at the base) - Maximum capacity: Up to 56 bottles (with one shelf installed)
Dimensions
- H × W × D (inches): 32.3 × 24.4 × 22.3
- H × W × D (mm): 820 × 594 × 566
Please verify cabinet dimensions before building custom cabinetry.
Temperature Performance
- Twin Process™ thermal regulation system
- Maintains precise and stable temperatures between 10°C and 14°C
***** Technical Specs *****
Cabinet Construction
- Cabinet walls insulated with 5 cm thick Cellular Quality Insulation, providing thermal performance comparable to up to 2 metres of natural earth insulation
- Passive ventilation system with charcoal filter for clean air circulation
***** Warranty *****
Press Release - Vibrations
The EuroCave products guarantee:
Each EuroCave wine cabinet has an individual identification number which enables tracing of its origin and authenticity. EuroCave will only warranty cabinets sold by authorized dealers:
Warranty for all EuroCave cabinets offered directly by EuroCave:
- Labour: 2 years
- Parts: 5 years
- Compressor (parts only): 5 years
Warranty for Revelation Series ONLY - 5 years parts and labor, 10 years rust proofing/corrosion
***** Product Manuals *****
Tech Sheet Solid Technical Door
Taking care of your wine cabinet
Comparison Chart of Revelation, PURE and Premiere
PURE SERIES
- EuroCave PURE Brochure
- EURO PURE-S: 74 Bottles
- EURO PURE-M: 146 Bottles
- EURO PURE-L: 182 Bottles
REVELATION SERIES
EuroCave Revelation Brochure
V-REVEL-L Information Sheet
V-REVEL-S Information Sheet
PREM SERIES
Prem Manual
Prem L (Spec Sheet)
Gamme Premier
EuroCave Dual Zone 6170DPremium (Spec Sheet)
Wine cabinets installations Première, Pure and Revelation Flush-fitting diagrams
Cabinet Loading with Presentation Shelf Options
***** Shipping Information *****
Large Item Shipping: Additional Shipping charges may be charged for accessory items ordered on their own without the cooling unit. Rosehill Reserves the right to contact you should shipping charges end up substantially higher than advertised on our website. You will have an opportunity to not complete your order at that time.
White Glove Delivery might be available for your location, and will be confirmed by a Rosehill representative upon order confirmation.
